Ascentest Releases AT105 EM Shileding/Absorbing Material Test System
Time：2013-10-16    Source：Ascentest

Ascentest has recently released AT105 Electroagnetic Wave Shileding/Absorbing Material Test System.



AT105 system consists of Agilent ENA/PAN/PNA-L Network Analyzer and Ascentest customized accessories and software.

With its user-friendly "Test Wizard" software, AT105 system automatically tests the following key parameters of the MUT(Material Under Test):

1. Shielding Effect: 30MHz~1.5GHz, according to ASTM 4935, GJB 6190-2008 & SJ20524-1995.
2. Permeability/Permittivity: 100MHz~18GHz
3. Reflection Loss/Attenuation: 45MHz~10GHz
4. Power Loss: 45MHz~6GHz



System Structure:



Test Results:
