| MPS Multi-Port RF / Microwave Switch Matrix |
| MPS (Multi Port Switch) Series Multi-Port RF / Microwave Switch Matrix routes 2 or 4 RF Signals to 6 / 8 / 12 / 24 or more ports.
The typical MPS applications are Vector Network Analyzer port expansion for multi-port RF / Microvave component testing, and multi-DUT testing for basestation, wireless terminals or mobile phones, as well as high-speed data cable testing. |
|
|
 |
|
|
|
| MPS-MUE Wireless RF & DC Power Switch Control Box |
| MPS-MUE consists of a SP6T RF Switch and a Relay Matrix, to simultaneously switch wireless RF signal and DC Power Supply.
The test system based on MPS-MUE can be used for Design Verification or NPI testing for Multiple (6 or more) UEs continuously without operation interruption. |
|
|
|
|
|
|
| AF5101 Automatic RF Shield Box |
| AF5101 is pneumatic automatic RF shield box with 60dB shielding (<3GHz) and all necessory interfaces for RF board test and final test. |
|
|
|
|
|
|
| AF5301 Functional Call Test Box |
| AF5301 Functional Call Test Box, , with RF / Audio / Visual test technologies, is one-stop tester for mobile phone MMI & Call test.
AF5301 provides audio shielding and 60dB (<3GHz) RF shielding, as well as all necessary RF / Data / Power interfaces, supporting fast DUT model switching by replacing the test jig and circuitry.
AF5301 can be controlled with simplified commands or software drivers.
AF5301 is ideal test tool for mobile phone production test with durability and stability, which greatly increases test efficiency and reduces production cost. |
|
|
|
|
|
AT900 Instrument Calibration Test System
