AT800 System is ideal RF Pre-Conformance & Design Verification test tool for Wireless Terminals (Mobile Phones, etc.) with different wireless technologies.
Furthermore, AT800 is all-in-one test system that supports multiple wireless standards on the same system hardware and software platform at the same time.
AT800 is affordable RF Pre-conformance test system, as customer's in-stock equipment, which meets the system requirements, can be integrated in the AT800 system, which greatly reduces the system overall cost for customers with some instruments on hand.
The system's advanced hardware and software designs ensure the proven high level test accuracy.
AT800 System is ideal RF quality assurance solution for Wireless Terminal Manufacturers, Test Labs, as well as OEM Manufacturers.
AT800 System covers the following standards (Test Specifications):
1. WiFi (IEEE 802.11a/b/g/n): IEEE 802.11-2007, IEEE 802.11n
2. Bluetooth 1.2/2.0/EDR/2.1: Bluetooth RF.TS/2.0.E.3
3. GSM / GSM-R / GPRS / EGPRS: 3GPP TS51.010-1
4. WCDMA / HSDPA / HSUPA / HSPA: 3GPP TS34.121-1
5. TD-SCDMA / HSDPA / HSUPA / HSPA: 3GPP TS34.122
6. LTE FDD & LTE TDD (so called TD-LTE): 3GPP TS 36.521-1
7. Related Regulations by FCC, ETSI, R&TTE. |
1. Delivered System, built on Mature, Flexible and Modular hardware and software platform.
2. AT800 Systems have been successfully adopted by the most famous mobile phone manufacturer, serving as RF Pre-Conformance and Design Verification test tool.
3. All Test Cases are strictly designed according to wireless standards (Test Specifications).
4. Accurate, Automatic & Efficient.
5. Very high performance / cost ratio.
6. Expandable, Upgradeable and Customizable, to support customer's specific test requirements and more wireless standards. |
